Best RV Deep Cycle Battery 48V 65AH LiFePO4 Battery Pack

Best RV Deep Cycle Battery 48V 65AH LiFePO4 Battery Pack

48v 65Ah LiFePO4 Battery Pack for Military Vehicle communications Specifications This pack comes with a very advanced BMS (battery management system) with Texas Instruments IC inside which protects the pack from damage during charge and discharge. This BMS also has temperature protection to keep...
Send Inquiry
Product Introduction

48v 65Ah LiFePO4 Battery Pack for Military Vehicle communications

Specifications



No.

Items

Specifications

1

Nominal Voltage

51.2V

2

Nominal Capacity

65Ah

3

Cell Inside

LiFePO4 3.2V 3300mAh cell

4

Configuration

16S20P

5

Standard Charge Current

0.2C-0.5C

6

Max. Charge Current

1C

7

Battery management System (BMS)

BMS-L16S

8

Continuous Discharge Current

70A

9

Peak Discharge Current

140A

10

Full Charged Voltage

58.4V(3.65V per cell)

11

Charge Cut-off Voltage

62.4V  (3.9V per cell)

12

Discharge Cut-off Voltage

32V  (2.0V per cell)

13

Net Weight

40kg

14

Dimensions

680*410*210mm

15

Connector

Anderson Connectors

16

Operating Temperature

Charging:  0°C ~ 45°C

Discharging: -20°C ~ 55°C

17

Storage Temperature

 (Recommended to store 20 ± 5°C for long term storage)

18

Cycle Life

2000 times (80% of initial capacity at 0.2C rate, IEC   Standard)



This pack comes with a very advanced BMS (battery management system) with Texas Instruments IC inside which protects the pack from damage during charge and discharge. This BMS also has temperature protection to keep the pack from getting too hot.



It is a high power BMS which will allow the pack to put out 50amps continuous (2400 watts) and 100 amp bursts (3840 watts) although running this much power will drastically reduce packs life expectancy. so we recommend to not run your battery too hard if you expect it to last over a couple hundred charges.



product-1-1

product-1-1



Advantages of 48v battery pack:

   1. Long life, large capacity and good shock resistance

   2. Low self-discharge and good discharge performance at low temperature

   3. Strong charging acceptance and quick-charging capability

   4. Strong over-discharge resistance and charge retention

   5. Maintenance-free and no acid or water for maintenance in usage

   6. Excellent large current discharge performance, and have obvious advantages in startup and climbing

   7. High temperature performance

   8. Environmental friendly

   9. Lighter weight smaller size

  10. Most safe no explosion no fire



Application

Military robot, Military vehicles, communications, RF amplifiers and charging stations, tourist coaches, yachts, wind and solar energy storage power, traffic signals.Strong configuration with nice soldering, not any moving at all,With bracket shelf to install the cells, which have more space for the cells air flow to release the heat when charging and discharging.High quality BMS to protect any incidents occurs.






Accessories

We use US Plug   EU Plug   Au Plug   UK Plug   Anderson    XLR    3 Pin Plug   XT60   XT90   DC to customize lithium & lifepo4 battery packs






or Current Lead: we use various wilre in 8 12 14 types to make battery packs applicable for e motorcycle, ess , solar energy storage, ebike , e scooter, airwheel, hay mower and so on.



product-1-1

product-1-1





Product Feature Description

Security fuel bonding process to ensure module consistency and safety

Adopting 94-V0 safety & fire-proof raw material

Inter-module high insulation designed with FPC current acquisition

High voltage insulation with 2000V insulated connection material

1/6 density of iron light packing engineering plastic material to increase journey capacity



Primary Competitive Advantages

Military specification with auto. Grade material

Long life span with low resistant and self-discharge

Optimum design with light packing

Customized configuration are accepted

OEM & ODM orders are welcome



For Current Lead: we use various wilre in 8 12 14 types to make battery packs applicable for e motorcycle, ess , solar energy storage, ebike, escooter, airwheel, hay mower and so on.
