Best RV Deep Cycle Battery 48V 65AH LiFePO4 Battery Pack
48v 65Ah LiFePO4 Battery Pack for Military Vehicle communications
Specifications
|
No. |
Items |
Specifications |
|
1 |
Nominal Voltage |
51.2V |
|
2 |
Nominal Capacity |
65Ah |
|
3 |
Cell Inside |
LiFePO4 3.2V 3300mAh cell |
|
4 |
Configuration |
16S20P |
|
5 |
Standard Charge Current |
0.2C-0.5C |
|
6 |
Max. Charge Current |
1C |
|
7 |
Battery management System (BMS) |
BMS-L16S |
|
8 |
Continuous Discharge Current |
70A |
|
9 |
Peak Discharge Current |
140A |
|
10 |
Full Charged Voltage |
58.4V(3.65V per cell) |
|
11 |
Charge Cut-off Voltage |
62.4V (3.9V per cell) |
|
12 |
Discharge Cut-off Voltage |
32V (2.0V per cell) |
|
13 |
Net Weight |
40kg |
|
14 |
Dimensions |
680*410*210mm |
|
15 |
Connector |
Anderson Connectors |
|
16 |
Operating Temperature |
Charging: 0°C ~ 45°C Discharging: -20°C ~ 55°C |
|
17 |
Storage Temperature |
(Recommended to store 20 ± 5°C for long term storage) |
|
18 |
Cycle Life |
2000 times (80% of initial capacity at 0.2C rate, IEC Standard) |
This pack comes with a very advanced BMS (battery management system) with Texas Instruments IC inside which protects the pack from damage during charge and discharge. This BMS also has temperature protection to keep the pack from getting too hot.
It is a high power BMS which will allow the pack to put out 50amps continuous (2400 watts) and 100 amp bursts (3840 watts) although running this much power will drastically reduce packs life expectancy. so we recommend to not run your battery too hard if you expect it to last over a couple hundred charges.


Advantages of 48v battery pack:
1. Long life, large capacity and good shock resistance
2. Low self-discharge and good discharge performance at low temperature
3. Strong charging acceptance and quick-charging capability
4. Strong over-discharge resistance and charge retention
5. Maintenance-free and no acid or water for maintenance in usage
6. Excellent large current discharge performance, and have obvious advantages in startup and climbing
7. High temperature performance
8. Environmental friendly
9. Lighter weight smaller size
10. Most safe no explosion no fire
Application
Military robot, Military vehicles, communications, RF amplifiers and charging stations, tourist coaches, yachts, wind and solar energy storage power, traffic signals.Strong configuration with nice soldering, not any moving at all,With bracket shelf to install the cells, which have more space for the cells air flow to release the heat when charging and discharging.High quality BMS to protect any incidents occurs.

Accessories
We use US Plug EU Plug Au Plug UK Plug Anderson XLR 3 Pin Plug XT60 XT90 DC to customize lithium & lifepo4 battery packs

or Current Lead: we use various wilre in 8 12 14 types to make battery packs applicable for e motorcycle, ess , solar energy storage, ebike , e scooter, airwheel, hay mower and so on.


Product Feature Description
Security fuel bonding process to ensure module consistency and safety
Adopting 94-V0 safety & fire-proof raw material
Inter-module high insulation designed with FPC current acquisition
High voltage insulation with 2000V insulated connection material
1/6 density of iron light packing engineering plastic material to increase journey capacity
Primary Competitive Advantages
Military specification with auto. Grade material
Long life span with low resistant and self-discharge
Optimum design with light packing
Customized configuration are accepted
OEM & ODM orders are welcome
For Current Lead: we use various wilre in 8 12 14 types to make battery packs applicable for e motorcycle, ess , solar energy storage, ebike, escooter, airwheel, hay mower and so on.





Why choose us?
- Our factory has a strong R&D team that can provide innovative solutions for our customers.
- Our employees care for each other in life, learn and encourage each other in work, and everyone appears in all positions of the enterprise with the attitude of master.
- We have a customer-centric approach and strive to meet our customers' needs.
- We pursue the policy of "enterprising, truth-seeking, rigorous and unity", continue to innovate, take technology as the core, regard quality as our life, and regard users as God, and we will wholeheartedly provide you with cost-effective self-control products and meticulous service.
- We provide technical support before and after the sale of our products.
- The company's integrity, strength and product quality have been recognized by the industry.
- As a supplier and manufacturer, we provide affordable prices for our products.
- We are committed to building a model enterprise with high quality Best RV Deep Cycle Battery 48V 65AH LiFePO4 Battery Pack, fine management, complementary industries, intelligent and efficient, and green and low-carbon.
- Our products have outstanding performance in extreme environmental conditions.
- With the company's strict and effective control over every production detail, we have gained the trust of many customers at home and abroad!
