6S 25C 10000mAh Battery For Multirotor

Custom high capacity and long endurance time aircraft lithium battery 6S 25C 22Ah for Multicopter

Origin: Shenzhen China,

P/N：6S 22.8V 25C 10000mAh

Rated Capacity:10000mAh

Standard Voltage:22.8V   Charge Current:20A   Charge time:1 hour

Size: 52*70*185（mm）

Applicant: big multirotor, UAV, UAS, Drone 22.2V or 22.8V

High Discharge platform, more powerful, long endurance time, increase the working efficiency.

lmost all Lithium Polymer batteries you buy today will come with a ‘C’ rating. The ‘C’ in C rating stands for Capacity. The C rating is the maximum, safe, continuous discharge rate of a pack as specified by the manufacturer, so when you see 20C printed on your label, it means it can be discharged at 20 times the pack’s capacity, ‘continuously’.

Capacity is usually measured in mAh and a popular cell size is 2200mAh. Therefore, so by way of example:

2200mAh 20C Cell = 2.2A x 20 = 44A continuous discharge

Along with the continuous discharge rate, some batteries display ‘burst’ discharge rate. This is typically twice the continuous discharge rate. It usually means the battery is capable of allowing twice the current, but only for a few seconds at a time.

Damage Avoidance

You will damage your batteries if you use them beyond these specifications. The idea is to stay well away from these limits. In theory, the higher the C rating, the better the battery. In high current draw applications such as 3D RC helicopters, high C rated batteries are essential. The trouble with 3D helicopters is that the cells are subjected to high current draws in hard maneuvers. The current draw spikes are sometimes beyond the limits of the battery. If the battery is pushed beyond its limits, the battery will get hot, the performance will drop and if pushed hard enough, possibly inflate and cause irreversible damage.

How Good is your Lithium Polymer Battery?

Please, please, please beware of ‘claimed’ C ratings! Most batteries now come from China and at present there seems to be no control on what manufacturers can print on their labels and no requirements to substantiate their claims. I’ve seen countless batteries clearly over specified which cannot deliver anywhere near their claimed current draw! On the flip side, I’ve also used and sold 20C packs which clearly outperform other manufacturers claiming 45C! It can be confusing to determine the genuine specifications as vaunted.

Please do your research, ask around and spend wisely – cheap and good as well as expensive and poor can still be found in the market today! I’ve tested hundreds of packs and to this day, I’ve never seen a pack perform beyond 35C. If you see anyone claim beyond 35C, you should be skeptical!

Balancing Lithium Polymer Batteries

Balancing is very important. If a pack is used and kept within its safe working limits, cells tend not to drift too far out of balance. Imbalanced cells can occur when the pack has been discharged too much. Sometimes a pack may just develop a bad cell. Balance charging will help detect an imbalance between cells and reduce the likelihood of overcharging other cells within the pack. For this reason, please ONLY balance charge your batteries.

Temperature

When charging your batteries, temperature is important. Never charge a battery that has been stored below 0ºC as you risk an explosion at these temperatures. Cold storage for LiPo cells is actually a good thing, but before charging them again always make sure your packs have had the chance to fully reach room temperature before commencing!

Why choose us?

Reminding:

1. if the alarming voltage setting is higher,then  the advent will be more oblivious ,and the recycleing life will be even longer.

2. Normally if replaced the new high voltage battery,the drone need to do any change at all,like the rotor,controlling module ,because the full capacity voltage is only 26.1V，just 0.9V higher.

We welcome you want us customized the battery pack for your UAV/DRONE,So you only need to provide us such details for the custom battery:

1.  Battery Capcity

2.  Rated Voltage,full Voltage

3.  Working current,peak current

4.  Motor power,qty

5.  Shape and size

6.  Battery weight

7.  Endurance time

8.  Wires

9.  Other requirements

10. Delivery time

There are the current type we already have the right solution!

Why choose us?

• Our LIPO batteries for drones are available at highly competitive prices without any compromise on quality.
• Relying on the enterprise spirit of "integrity, dedication, and people-oriented", excellent business philosophy, advanced technical support, pragmatic work attitude, and considerate service, our company has been deeply rooted in 6S 25C 10000mAh Battery For Multirotor and has won the praise of our customers. Recognition and market reputation.
• Our convenient ordering system makes it easy for customers to purchase LIPO batteries for drones online.
• Please tell us the product you are interested in, we will provide you with the best price and the best solution.
• At our factory, we use advanced technology and processes to produce LIPO batteries for drones.
• Our company has grown rapidly with scientific management methods, continuous improvement of manufacturing technology and innovative manufacturing concept.
• We offer customized solutions for clients who require unique LIPO batteries for drones.
• After years of efforts and steady development, our company has formed a certain scale and successfully sold its products all over the world.
• We use only the highest quality materials in the production of our LIPO batteries for drones.
• We take it as our mission to become an excellent national brand. Through continuous development, we will surely become an internationally competitive 6S 25C 10000mAh Battery For Multirotor manufacturer and brand operator.
