6S 22.8V 16000mAH 25C Quadrotor Battery
6S 22.8V 16000mAh 25C Quadrotor Battery
Origin: Shenzhen China,
P/N:6S 22.8V 25C 16000mAh
Rated Capacity:22Ah
Standard Voltage:22.8V
Pure Lithium Cobalt battery
Charge Current:20A Charge time:1 hour
Size:
Applicant: big multirotor, UAV, UAS, Drone 44.4V or 45.6V for maping, agriculture, disaster saving
High Discharge platform, more powerful, long endurance time, increase the working efficiency.
Battery type | High rate polymer lithium battery 4.35V cells | Product | 6S 22.8V 25C 16000mAh |
recharging current | 1C (satisfied with 3C charging) | Discharge rate | Continuous 25C/Instant 40C |
Finished weight | 2000g | Size | 75*91*195(mm) (thickness*width*length) |
Combination method | 6S1P | Warranty | 90 days/180 days |
Outgoing | Discharge line: 10AWG silicone wire, exposed line length is 145mm Charging line: 22AWG silicone line, exposure line length 70mm | ||
plug | Discharge end: XT90 (welding XT60/XT150/AS150, charge another charge.) Charging end: JST-XH balanced plug | ||
Application | Plant protection, surveying and mapping, reconnaissance,aerial and aerial drones . | ||
Relative to ordinary 4.2V battery, High-voltage battery (4.35V) has longer battery life.
Stronger power. Note: The weight, cycle life, and charge are the same as those of ordinary batteries. with high-voltage batteries, There is no need to make any changes to drone equipment. Such as ESC, motor, flight control.

Why choose us?





Reminding:
1. If the alarming voltage setting is higher,then the advent will be more oblivious ,and the recycleing life will be even longer.
2. Normally if replaced the new high voltage battery,the drone need to do any change at all,like the rotor,controlling module ,because the full capacity voltage is only 26.1V,just 0.9V higher。
We welcome you want us customized the battery pack for your UAV/DRONE,So you only need to provide us such details for the custom battery:
1. Battery Capcity
2. Rated Voltage,full Voltage
3. Working current,peak current
4. Motor power,qty
5. Shape and size
6. Battery weight
7. Endurance time
8. Wires
9. Other requirements
10. Delivery time
There are the current type we already have the right solution!
Part No. | Capacity | Rated voltage | Discharge Rate | Continuous Current A | Peak Current | Dimension (T x W x L)mm | Weight | ||
6S 25C 10000mAh | 10000 | 22.8V | 25C | 250 | 500A | 52 | 70 | 185 | 1350g |
6S 25C 12000mAh | 12000 | 22.8V | 25C | 300A | 600A | 60 | 70 | 185 | 1540g |
6S 25C 12000mAh | 12000 | 22.8V | 25C | 300A | 600A | 46 | 91 | 195 | 1540g |
6S 25C 14000mAh | 14000 | 22.8V | 25C | 350A | 700A | 53 | 91 | 195 | 1710g |
6S 25C 16000mAh | 16000 | 22.8V | 25C | 400A | 800A | 76 | 70 | 189 | 2000g |
6S 25C 16000mAh | 16000 | 22.8V | 25C | 400A | 800A | 56 | 91 | 199 | 2010g |
6S 25C 22000mAh | 22000 | 22.8V | 25C | 550A | 1100A | 66 | 91 | 215 | 2630g |
12S 25C 12000mAh | 12000 | 45.6V | 25C | 300A | 600A | 66 | 91 | 192 | 3100g |
12S 25C 14000mAh | 14000 | 45.6V | 25C | 350A | 700A | 106 | 91 | 192 | 3430g |
12S 25C 16000mAh | 16000 | 45.6V | 25C | 400A | 800A | 112 | 91 | 199 | 4000g |
12S 25C 22000mAh | 22000 | 45.6V | 25C | 550A | 1100A | 132 | 91 | 215 | 5200g |
12S 25C 32000mAh | 32000 | 45.6V | 25C | 400A | 800A | 112 | 91 | 210 | 8000g |
20S 25C 32000mAh | 32000 | 76V | 25C | 400A | 800A | 93 | 183 | 210 | 13800g |
