22.2V 4200mAH 35C RC Batteries
22.2v 4200mah 35c RC battery
|
Battery type |
High rate polymer lithium battery 4.35V cells |
Product |
6S 22.8V 25C 4200mAh |
|
charging current |
20A |
Discharge rate |
Continuous 35C/peak 40C |
|
Finished weight |
5300g |
Size |
43.5*44*136mm |
|
Combination method |
6S1P |
Warranty |
90 days/180 days |
|
Outgoing |
Discharge wire: 10AWG silicone wire, exposed line length is 145mm Charge wire 22AWG silicone line, exposure line length 70mm |
||
|
plug |
Discharging connector: XT90 (welding XT60/XT150/AS150, charge another charge.) Charging connector: JST-XH balanced plug |
||
|
Application |
RC battery, Electric tool long endurance time Battery . |
||
-
Batteries are composed of a series of cells from one to several and may be series or parallel connected.
-
Individual cells or a single cell battery in Lithium Ion or LiPoly is anywhere from 3.2 to 3.7 volts depending on chemistry.
-
Although cell voltage remains identical for a given chemistry current capacity of cells can be different.
-
All cells in a given battery will, however, have the same current capacity.
-
If two cells are connected in series (positive to negative) voltage will double but current capacity will stay the same.
-
Two cells in parallel (positive to positive and negative to negative) doubles current capacity but voltage stays the same.
-
The batteries we use are usually a set of cells of the current capacity we need wired in series to produce the voltage we need.
-
For Example a LiPo 3S1P designation refers to three 3.7 volt LiPo cells in series producing a nominal 11.1 volts.
-
It is possible to combine two or more batteries in parallel to double or further increase our total energy capacity.
-
It is also possible to combine two or more batteries in series to double or further increase the voltage.
-
When combining batteries in parallel (or series) they must have identical characteristics (voltage and current capacity).
-
For Lithium Ion we may make a battery with series and parallel cell interconnection for both the voltage and current we need.
BatterySafety
Applicant: big multirotor, UAV, UAS, Drone ,can be with 14kg,16kg,big UAV for agriculture pesticide spraying.
High Discharge platform, more powerful, long endurance time, increase the working efficiency.
We are packed with vibration-proof & fire-proof material and our luxury battery box ensuring you get your battery in perfect condition. An automatic procedure & Computer system battery cell matching process ensures the batteries stability and quality. All the batteries will be done with full function testing and mechanical testing like the vibration…..
Note: For the same capacity, the high-voltage battery can increase the flight time by 15-25% and the weight does not increase.
Why choose us?
Reminding:
1. If the alarming voltage setting is higher,then the advent will be more oblivious ,and the recycleing life will be even longer.
2. Normally if replaced the new high voltage battery,the drone need to do any change at all,like the rotor,controlling module ,because the full capacity voltage is only 26.1V，just 0.9V higher。
We welcome you want us customized the battery pack for your UAV/DRONE,So you only need to provide us such details for the custom battery:
1. Battery Capcity
2. Rated Voltage,full Voltage
3. Working current,peak current
4. Motor power,qty
5. Shape and size
6. Battery weight
7. Endurance time
8. Wires
9. Other requirements
10. Delivery time
There are the current type we already have the right solution!
|
Part No. |
Capacity |
Rated voltage |
Discharge Rate |
Continuous Current A |
Peak Current |
Dimension (T x W x L)mm |
Weight | ||
|
6S 25C 10000mAh |
10000 |
22.8V |
25C |
250 |
500A |
52 |
70 |
185 |
1350g |
|
6S 25C 12000mAh |
12000 |
22.8V |
25C |
300A |
600A |
60 |
70 |
185 |
1540g |
|
6S 25C 12000mAh |
12000 |
22.8V |
25C |
300A |
600A |
46 |
91 |
195 |
1540g |
|
6S 25C 14000mAh |
14000 |
22.8V |
25C |
350A |
700A |
53 |
91 |
195 |
1710g |
|
6S 25C 16000mAh |
16000 |
22.8V |
25C |
400A |
800A |
76 |
70 |
189 |
2000g |
|
6S 25C 16000mAh |
16000 |
22.8V |
25C |
400A |
800A |
56 |
91 |
199 |
2010g |
|
6S 25C 22000mAh |
22000 |
22.8V |
25C |
550A |
1100A |
66 |
91 |
215 |
2630g |
|
12S 25C 12000mAh |
12000 |
45.6V |
25C |
300A |
600A |
66 |
91 |
192 |
3100g |
|
12S 25C 14000mAh |
14000 |
45.6V |
25C |
350A |
700A |
106 |
91 |
192 |
3430g |
|
12S 25C 16000mAh |
16000 |
45.6V |
25C |
400A |
800A |
112 |
91 |
199 |
4000g |
|
12S 25C 22000mAh |
22000 |
45.6V |
25C |
550A |
1100A |
132 |
91 |
215 |
5200g |
|
12S 25C 32000mAh |
32000 |
45.6V |
25C |
400A |
800A |
112 |
91 |
210 |
8000g |
|
20S 25C 32000mAh |
32000 |
76V |
25C |
400A |
800A |
93 |
183 |
210 |
13800g |
Why choose us?
- Our commitment to continuous improvement means that we are always striving to make our LIPO batteries for drones even better.
- Our company adheres to the tenet of seeking development with sincerity and survival with quality, and is brave to innovate and provide customers with suitable solutions.
- At our factory, we use advanced technology and processes to produce LIPO batteries for drones.
- Our company adheres to the business principle of 'survive by quality, develop by reputation', create first-class quality, and constantly provide economical and practical 22.2V 4200mAH 35C RC Batteries and efficient and perfect after-sales service according to the needs of customers.
- We understand the importance of delivering LIPO batteries for drones that match our clients’ specific requirements.
- We share the hardship and hardship with all employees, and we share the success and harvest.
- Our LIPO batteries for drones are of the highest quality and are backed by professional service.
- We do not focus on how much fortune we can make, instead we aim to obtain high reputation and be recognized for our goods.
- We use only environmentally friendly and sustainable materials in the production of our LIPO batteries for drones.
- We believe that corporate culture really gives the direction of sustainable development and the goal of forging ahead.
