AGV RGV Lithium Ion Battery 24V 40AH

Custom AGV/RGV Lithium Ion battery 24V 40AH Main classical AGV Batteries WHY LITHIUM-ION BATTERY?

Send Inquiry

Product Introduction

Custom AGV/RGV Lithium Ion battery 24V 40AH

1	Rated Capacity	40.0Ah	Standard discharge(0.5C)after standard charge(0.5C)
2	Minimal Capacity	39Ah
3	Nominal Voltage	25.6V
4	Cycle Life	Higher than 60% of the Initial Capacity of the battery pack	1)Charge: 0.5C CC to 29.2V, then CV till current to 0.05C 2)Rest: 30min. 3)Discharge: 0.5C to 20.0V 4)Carry out 1200cycles (Temperature:20±5°C)
5	Discharge cut-off voltage	18.4V	20.0V(recommended)
6	Charging cut-off voltage	31.2V	29.2V(recommended)
7	Cell and assembly method	IFR26650EC-3.3AH	8S12P
8	Packing material	ABS
9	Standard charge	0.5C constant current(CC) charge to 29.2V,then constant voltage (CC)29.2V charge till charge current decline to ≤0.05C
10	Standard discharge	Constant current 0.5C to 20.0V
11	Maximum Charge Current	60A	30A recommended for better peformance and longer life
12	Continuous Discharge Current	60A
13	Operation Temperature Range	Charge: 0~45°C	60±25%R.H.
13	Operation Temperature Range	Discharge: -10~50°C	60±25%R.H.
14	Storage Temperature Range	Less than 1 year : 0~25°C	60±25%R.H. at the shipment state
14	Storage Temperature Range	Less than 3 months:-5~35°C	60±25%R.H. at the shipment state
15	Approx Weight	23.5Kg
16	Maximum Dimension	customize

Li-Ion (Lithium-Ion) is the most common cell for mobile applications – Ranging from mobile phones to usage of space applications. These cells are very easy to come-by, the problem is assembling them correctly, with the proper electronics & control and verifying their performance.
Why do we like Li-Ion cells	When we do not recommend to use Li-Ion cells
Because Li-Ion from large companies are very reliable	When our customer askes for very high currents. The Li-Ion has relatively high Internal Resistance and therefor drops voltage in high currents
Because Li-Ion cells are available. Most of the brands are easy to purchase.	When our customer has complex volume and wants max capacity. Li-Ion is common in a few basic dimensions. Most of the times can't reach 100% volume usage.
Because Li-Ion has also very reliable and cost effective brands.	When our customer wants minimum weight. OUR LiPo is better than Li-Ion
Because the majority of Li-Ion (from large companies) have all the certifications needed	When our customer has a high temperature problem (again, that IR)

Main classical AGV Batteries

WHY LITHIUM-ION BATTERY?


Our AGV 24 Volt Battery products are cost-effective and efficient.
We always attach importance to product quality, believe that innovation is the source of enterprise development, management is the core of the enterprise, and quality is the life of the enterprise. We strive to provide customers with high-quality products.
We offer a wide range of spare parts and accessories for our AGV 24 Volt Battery products.
Our company has gone from domestic market to international market, and opened the way to internationalization.
We offer customization options for our AGV 24 Volt Battery products.
We advocate the sense of innovation, create an open and inclusive innovation environment, improve the innovation mechanism, stimulate innovative thinking and encourage innovative behavior.
You can trust us for timely delivery of your AGV 24 Volt Battery products.
We are willing to win more partners with high-quality performance of our AGV RGV Lithium Ion Battery 24V 40AH and service quality, and take shaping, upgrading and consolidating brands for customers as our unremitting efforts.
We're a Chinese factory offering professional AGV 24 Volt Battery products and services.
We promote the realization of the maximization of comprehensive economic, social and environmental values and sustainable development.
